Inline concentration monitor for NMP Model ZXRN0-100 Simplicity and best Versatile Process Management
Product Description
The Model ZXPN0-10 is specially designed for the measurement of N-methylpyrrolidone solution
Specifications
| Model | ZXRN0-100 |
| Measurement range | NMP 0.00-100.00% ND 1.33299-1.47285 |
| Resolution | 0.01% or 0.1% |
| Measurement accuracy | ±0.1% |
| Measurement temperature | 5.0 to 100.0℃ (Automatic Temperature Compensation range) |
| Measure Rage Setting | Setting by button |
| Display Menu | Refractive index(ND) NMP Concentration % Temperature T |
| Output Mode | Two lines 4-20 mA (NMP%Temperature ) Ethernet 485 |
| Power | DC 24V |
| Cable | Standard configuration Power line1.5m Signal line 1.5m Ethernet 485 Wireless standby interface |
| Material of sample contact site | Prism sapphire Sample contact site standar 316L( Can be customized) |
| Optical source | LED(the wave length approximate to D line ) |
| Max Pressure | Max tolerance 2 MPa |
| Environment temperature | 5℃-40℃ |
| Level of protection | IP67 |
Operation manual for Inline refractometer
Conditions to be followed
Use the instrument at altitudes below 2000 meters (altitude).
Use the instrument indoors.
The using temperature shall be between 5℃ to 40℃.
Do not change the ambient temperature of the instrument suddenly.
Do not place the instrument in a place where it may be affected.
Do not use the instrument in areas with large amounts of dust and strong vibrations.
Do not put the instrument in a place where the temperature is very low.
Do not put the instrument in a damp place.
Do not put heavy objects on the instrument.
Do not install the instrument in direct sunlight or near the heating source. Do not install in the
environment of dust or exposure to corrosive gases.
When installing, please pay special attention to avoid the great impact of the instrument.
Packing: Standard exporting package carton box wooden carton or As customer request
Shipping : The products will be shipped via FEDEX DHL TNT Special-line ,sea shipping ,air transportation etc.To destination countries .
